Dc24V 12V side viewing 16mm16mm size flex silicone neon led tube
Specification
| Catalog | Dc24V 12V side viewing 16mm16mm size flex silicone neon led tube |
|---|---|
| Model | RL-Neon-1616-2835-24V 12V -white |
| LED Type | 2835 |
| Warranty | 2 years |
| Working Voltage | DC12V 24V optional |
| Power | 10W/M(max) |
| Lamp Chip Brand | sanan |
| LED Quantity | 120leds/M |
| Cutting Unit | every 6LED can be cut as a individual part |
| Lumen for each 2835 led | >22lm |
| Lamp Quality | Pure copper base and gold wire |
| PCB thickness | 25um25um |
| beam viewing | 120 degree |
| Color | white |
| waterproof Grade | IP54 non waterproof |
| Size | 16mmX16mm |
Download the datasheet here please
Advantage of New neon flex led tube
1. there is no dark area and No light spot for all type of flex silicone Neon LED tube series,
2. it can be folded and bent without problem.--360 degree bendable -
3. Easy to be installed and transported .
4. applied well in all kinds of High-end venue and outdoor use (Ip rate: 65)
5. take the advantage of unique optical technique and special housing design ,
it increases the intensity and uniformity of light greatly ,anti UV silicone coating ,
no color change outside within 2 years warranty
6. all series belong to low voltage flex led strip,voltage varies from DC5V-DC12v，
can be cut at 1led,the small pixel pitch 1.25cm optional.
7. various designed and customized led quantity and all kinds of control method optional
8. Packing : Static bag seal packing(locking static bag + moisture-proof desiccant)
9. 5m/reel(length can be customized as the customer requirements)
